144L S/S Double Drawer Freezer with Sea Lock Catch and Flush Frame DW180 BTX VFDW180.2BTXPFTOCX

STAINLESS STEEL DRAWER REFRIGERATORS-FREEZERSTHE NEW OCX2 SERIES The Stainless Steel Drawer Series has been completely updated in both design and function. The stylish new square edge door design with the Steelock positive latch handle has the added functionality of a vent position for air circulation during periods of non-use preventing mould or bad odours in the fridge. The single section, stainless steel fitting frame allows the fridge to be securely fixed either with the door flush or proud of your furniture and has integrated vent slots to improve air flow and the efficiency of the cooling unit behind. Technical Data

Total volume lt	144
Upper compartment volume lt	80
Lower compartment volume lt	64
Net weight kg.	56
Power supply	12/24Vdc (also available with dual electronic box 12/24Vdc - 100-240Vac 50/60Hz)
Nominal consumption	45W
Overall width mm.	666
Overall height mm.	866
Overall depth mm.	590 Dimensions overall dimension with Door Inside mounting flange built-in dimension with Door Inside - Door Outside mounting flanges Features & Plus Double Door Position One single fitting frame for 2 versions: DOOR INSIDE and DOOR OUTSIDE Steelock design and technology into a "top" lock (Flush Flange only) LED Thermostat An elegant thermostat for a perfect temperature setting Vent Position The new Steelock latch has a vent position for air circulation during periods of non-use. Venting Frame New hole system for better air circulation and cooling efficiency Drawers multi purpose spacious and sturdy drawers Stainless steel 316 Models of the drawer series are made of stainless steel 316 Led light LED light for a perfect lighting in your fridge D power (optional) 12/24Vdc - 100-240Vac 50/60Hz dual electronic control Literature DW-CDW series user guide
